The universal laser marking system LAS 28 XL from Systemtechnik Hölzer GmbH can be used for a very wide range of marking applications. With the integrated fiber laser you can mark almost all materials such as steel, carbide, aluminum and plastics.

Depending on the requirements, the system can be equipped with a 20, 30 or 50 watt fiber laser. For permanent marking, the use of the laser is necessary in many industries.

With the powerful laser software, texts, numbers, 2D codes, QR codes and logos can be realized with just a few clicks without extensive programming knowledge. Serial and article numbers are automatically incremented by the software after prior setting. In addition, the software can read data (variable information such as drawing numbers, project designations, etc.) from existing tables and automatically transfer them to predefined areas. The use of a hand scanner is also possible.

The standard equipment includes a laptop incl. holder with Windows operating system and laser software. Optionally, the laser model LAS 28 XL can be equipped with a rotary axis (3-jaw chuck) for marking cylindrical parts. Further options, such as lateral extension arms for marking long parts, movable Z-axis, drawer systems, etc., can be realized.

Product Data

  • Fiber Laser 20 W (optional: 30 W, 50 W)
  • Laser class 1
  • Wavelength 1064nm
  • Marking field size 150x150mm
  • marking software EZCAD in German / English
  • Pilot laser (simple preview)
  • focus finder (simple focus adjustment)
  • max. part height approx. 300mm
  • electrically adjustable Z-axis
  • Laptop incl. holder with operating system Windows
  • Frame made of aluminum profile
  • Air cooled
  • Door width approx. 700mm / Door height: 420mm
  • Connection 230V
  • Dimensions: approx. 900 x 800 x 1900 mm (LxWxH)
  • Weight: approx. 100 Kg
